Pull-out, Kesseböhmer Dispensa Tandem Diagonal Junior
Pull-out, Kesseböhmer Dispensa Tandem Diagonal Junior
Supplier:
Häfele
Category:
Kitchen Organisation
Pull-out, Kesseböhmer Dispensa Tandem Diagonal Junior
Cabinet height from 600 mm, reversible, anthracite
Article details
For cabinet width
300 mm
For internal cabinet width
262 – 268 mm
For internal cabinet depth
482 – 530 mm
For internal cabinet height
≥600 mm
Version
Reversible
Model
tandem Diagonal Junior
Type of pull out
Single extension
Load bearing capacity
30.0 kg
Material
Steel
Features
Reversible
Order reference
Please order hook-in shelves in Classic/Style versions separately.
Supplied with
1 frame 218x35x550 mm
1 lateral guide track
1 bottom runner S1
1 bottom runner S2
1 follower, bottom
1 door connection, bottom L=87.5 mm
1 accessory bag
1 control lever l=270 mm
1 set of installation instructions
Additional information attributes
Soft closing mechanism runs via the hinge.
Please use hinge with soft closing mechanism.
Pull-out, Kesseböhmer Dispensa Tandem Diagonal Junior, Datasheet
