Sliding Door Hardware, Slido D-Line11 50P to 120P, set without running track

Sliding Door Hardware, Slido D-Line11 50P to 120P, set without running track

for 1-leaf and 2-leaf wooden sliding doors, ceiling installation and wall mounting, door height adjustable, With soft and self closing mechanism on both sides, door width ≥744 mm

Item details

Soft and self closing mechanism:
Low opening force – easy and convenient operation
Tested with increased closing speed up to 0.5 m/s
Can be retrofitted or replaced at any time
Accessibility: Opening force with door weight 50 kg: 20 N / 80 kg: 23 N
Shock absorber:
Closing speed with shock absorber tested up to 0.4 m/s

Number of doors

1.00

For door material

wood

Model

50P / 80P / 120P

Controller installation options

Ceiling installation, Wall mounting

Adjustment facility

Height: (3/16") +/-5

Area of application

For 1-leaf and 2-leaf sliding doors

Note on door weight

Per door

Running position

Top

Adjustment facility

height adjustment

Installation

Suspension with screwed on support flange

Order reference

Please order track, panels and accessories separately. Order 2 sets for 2-leaf sliding doors.

Supplied with

2 running gears with soft and self closing mechanism
1 clear threshold floor guide
2 release device with stopper for soft and self closing mechanism

Additional information

No end cap is available for ceiling installation with fascia on both sides. A pair of end caps can be attached end to end and glued vertically in the centre of the running track (optional).
Please note when using shock absorber with retaining spring: The door may not close completely if the closing speed is too low, if it is too high, the door may bounce back slightly.
For sets without or with soft and self closing mechanism on one side: If required, soft and self closing mechanism or shock absorber can be retrofitted.

End cap for ceiling installation with fascia on both sides not available. One pair of end caps can be glue fixed vertically in the centre of the running track (optional).

Item code: 940.83.008
